BMS voltage cut of 10.1 v Charging is 12.6 to 18v is ok NOTE:01 1) This board is not suit high power electronic tools, if use for screwdriver and drill,electric bike series make,fishing machine , please don't buy this. Pcb Bms For Drill Motor 11.1V 12.6V Lipo Cell Module BMS activate method : Use 12.6V Li-ion charger to charge it Scope: Nominal voltage of 3.6V, 3.7V lithium battery (including 18650,26650, polymer lithium battery) Product Size: 42 * 60 * 3.4mm (balanced version) Product weight: 9.8g (balanced version) Charging voltage: 12.6V - 13.6V Continuous discharge current (upper limit): 40A (if the cooling environment is not good, please reduce the load current use) Continuous charge current (upper limit): 20A Balance version: suitable for starting current below 80A, power 135W below the drill. Note 02 : try not to put a good battery and poor battery mixed together! Note 03 When the load of the brush motor is used, try to connect a non-polar capacitor (withstand voltage above 25V, capacity 10uF-100uF) to the motor's positive and negative terminals to prevent the reverse spike from the motor. Break the MOS tube.
DC 300W 20A CC CV Constant Current Adjustable Step Down Converter Voltage Buck Current Source Module
Specifications: Input Voltage: 6V to 40V DC(10V to 40V is suggested) Output Voltage: 1.2V to 36V DC Output Current: 20A(max.), 15A(suggested) Efficiency: 95%(24V to 12V, 20A) Output Ripple: ≤50mV Wiring Method: Terminal Short Circuit Protection: Self-recovery(cannot short circuit for long time) Size: 60 x 53 x 27mm / 2.36 x 2.08 x 1.06" VO+: Output positive VO-: Output negative +IN: Input positive -IN: Input negative CV: Output voltage adjustment CC: Output current adjustment EN: Enable, low voltage level shut off output; suspension, high voltage level is effective When input and output is common grounded, no-load CV output constant voltage,CC output constant current
Mini DC-DC 4.5V-35V 5A 90W PWM DC Motor Speed Controller Module Speed Regulator Control Adjust Adjustable Board Switch 12V 24V
Working voltage: DC4.5V-35V
Output current: 0.5A
Output power: 90W (maximum)
PWM frequency: 20KHz
Product size: 30mmx26mmx14mm/1.18x1.02x0.55''
Product weight: 14g
1. DC positive and negative terminals do not reverse, otherwise the governor may be damaged.
2. The motor can be divided into positive and negative directions. When the direction of operation is not consistent with the expectation, the direction can be changed by adjusting the line order.
3. Adjusting the potential meter knob can change the duty cycle of the governor and change the speed of the motor.
1 x Mini 5A 90W PWM 4.5-35V DC-DC Motor Speed Controller Module Regulator Adjustable
* Automatic identification system voltage, 12V 24V auto recognition * Humanized LCD displaying and double button operation of man-machine interface. * Completed technical data for setup and modify. * High efficiency intelligent PWM 3 stage charging. * The load control mode can be selected, the timer function can be reset for street light at night. * Reliable over voltage protection, short circuit protection, over load protection, overcharge protection, over discharge protection. * Accurate temperature compensation by external battery temperature sensor, correcting the charging and discharging voltage automatically, improving the battery lifetime. * Roundly reverse connected protection. Taiwan origin made MOSFET, anti-burnout * Dual PV input * Support charge to lithium battery(only available in FT2024-10A and FT2024-20A, not available in FT4024, FT6024 and FT6048) * Offer equalization charge to VRLA type AGM, GEL, and flooded lead-acid battery, extend the service life of all these types of lead-acid batteries * Imported microprocessor, the program can be re-recorded when an error occurs during the programming process, no need to replace the entire microprocessor * The input terminals of the photovoltaic array, battery, and load are all made of copper alloy, which is corrosion-resistant, low-impedance, and high-conductivity. * Positive ground capable which is with common positive grounding
- Dimensions: 48 * 40mm
- Temperature control mode: ON / OFF
- Temperature range :50-110
- Output voltage: for DC 12V
- Output power: 10A relay
- Hysteresis accuracy: 0.1
- Refresh rate: 0.5S
- High temperature protection 0-110
- Supply voltage: for DC 12V
- Static current: ≤ 35MA, attract current ≤ 65MA
- Measurement input: NTC (10K 0.5%) Waterproof Sensor
- Environmental requirements: -10 ~ 60 Humidity 20% -85%
